DJI Ronin-SC

Description

The DJI Ronin-SC is a compact 3-axis handheld gimbal stabilizer released in 2019, specifically designed for mirrorless cameras. It offers professional-level stabilization in a lightweight, portable package ideal for solo filmmakers, vloggers, and content creators who need smooth cinematic footage without the bulk of larger gimbals like the Ronin-S.

Key Features
• Lightweight & Portable — Total weight of about 1.1 kg (gimbal ~830g + grip ~258g). Magnesium, aluminum, and composite construction make it durable yet easy to carry. Folds down to compact dimensions (220 × 200 × 75 mm) for travel.
• 2kg Payload Capacity — Supports a wide range of mirrorless camera + lens setups (tested up to 2.0 kg) while delivering smooth, stabilized shots.
• Axis Locks — Built-in locks on pan, tilt, and roll axes simplify balancing and transportation. Quick position lock system allows fast remounting.
• Long Battery Life — Intelligent BG18 grip battery provides up to 11 hours of runtime. Charges in about 2.5 hours via USB-C.
• Intuitive Controls — Responsive joystick, Mode (M) button, record button, and front trigger for quick mode switching (PF, F, L, etc.). Supports shutter and focus control for most camera brands via cables or Bluetooth.
• Creative Modes — Panorama, time-lapse, motion time-lapse, 360° rolls, and more. Virtual joystick in the Ronin app for remote control.
• Accessory Ecosystem — Compatible with DJI Focus Motor, Focus Wheel, Command Unit, and other RSA (Ronin Series Accessories). Phone holder included for monitoring.
• Stabilization Performance — Angular vibration range of ±0.02°. Maximum controlled rotation speed of 180°/s per axis. Unlimited 360° pan rotation.
It excels for run-and-gun shooting, travel vlogging, and one-handed operation. Note: It lacks the foldable design and higher payload of the later RSC 2 (which supports 3kg and adds an OLED screen and SuperSmooth mode).

Technical Specifications
Stabilization
• Axes: 3-axis (Pan, Tilt, Roll)
• Angular Vibration Range: ±0.02°
• Max Controlled Rotation Speed: 180°/s (all axes)
• Mechanical Endpoint Range: Pan 360° continuous, Tilt -202.5° to +112.5°, Roll -95° to +220°
• Controlled Rotation Range: Pan 360° continuous, Tilt -90° to +145°, Roll ±30°

Battery
• Model: RB2-2450mAh-7.2V (18650 LiPo)
• Capacity: 2450 mAh / 17.64 Wh
• Max Runtime: 11 hours
• Charging Time: ~2.5 hours (5V/2A)
• Charging Temperature: 5°C to 40°C

Build & Dimensions
• Weight: Gimbal ≈830g, Grip ≈258g, Tripod ≈160g (total ~1.1kg)
• Folded: 220 × 200 × 75 mm
• Unfolded: 370 × 165 × 150 mm
• Operating Temperature: -20°C to 45°C

Connectivity
• Bluetooth 5.0
• Ports: USB-C, Camera Control Port, Accessory Port, RSA Port, 1/4” and 3/8” mounting holes
App — DJI Ronin app (iOS 9+ / Android 5.0+) for calibration, customization, and advanced features.

What’s in the Box (Standard Kit)
• Ronin-SC Gimbal ×1
• BG18 Grip (with built-in battery) ×1
• Extended Grip/Tripod ×1
• Quick-Release Plate ×1
• Camera Riser ×1
• Phone Holder ×1
• Lens Support ×1
• Multi-Camera Control Cables (various types)
• Carrying Case ×1
• Other small accessories (wrench, port covers, etc.)
Pro Combo adds: Focus Wheel, External Focus Motor, and RSS Splitter for enhanced focus pulling.

Camera Compatibility
The Ronin-SC works best with mirrorless cameras from Sony, Canon, Nikon, Panasonic, Fujifilm, and others. It supports a broad list of lenses as long as the total payload stays under 2kg. Check DJI’s official compatibility list for your exact camera + lens combo, as balancing and full control (shutter/focus) depend on the setup. It is not optimized for heavy DSLRs (use Ronin-S for those).
Popular compatible examples include Sony A7 series, Canon EOS R/M series, Panasonic GH/Lumix, and Nikon Z series with lighter lenses.

The DJI Ronin-SC remains a solid, affordable choice for lightweight mirrorless setups if you prioritize portability and long battery life over the latest upgrades. It delivers reliable stabilization for professional-looking footage on a budget.
